Heavy-Duty Smart Compactor Shelving System | High-Density Archive Storage Solution
Core Advantages & Selling Points
Space Maximization
Eliminates the need for multiple fixed aisles. By consolidating access into a single moving aisle, it increases storage capacity by up to 80% compared to traditional static shelving.
Uncompromising Safety
Equipped with multi-level safety mechanisms including infrared anti-collision sensors, emergency stop buttons, and anti-tilt devices to ensure the absolute safety of both personnel and valuable assets.
Silent & Smooth Operation
Powered by a 24V low-voltage brushless DC motor and precision double-row chain drive, ensuring whisper-quiet movement and effortless gliding even under maximum load capacity.
Smart Integration Ready
Features an intuitive Android-based touchscreen interface and CAN-bus architecture, allowing seamless integration with environmental monitoring, access control, and existing archive management systems.
Product Details & Specifications
Product Advantages
- Ultimate Space Efficiency: Eliminates fixed aisles, increasing storage capacity by up to 80% compared to traditional static shelving.
- Robust Construction: Made of premium SPCC cold-rolled steel with anti-corrosion electrostatic powder coating, ensuring long-lasting durability.
- Intelligent & Safe Operation: Features 24V low-voltage DC brushless motors, infrared anti-collision sensors, and emergency stop mechanisms to protect both users and assets.
- Customizable Configurations: Adjustable shelf heights and modular designs easily accommodate A4 files, oversized blueprints, heavy ledgers, and more.
Product Limitations
- Floor Load Requirements: Due to the high-density storage and steel structure, the system requires a high floor load-bearing capacity (typically ≥800kg/㎡).
- Initial Investment: The motorized drive system and smart control panels result in a higher upfront cost compared to basic static shelving.
- Installation Complexity: Requires precise floor leveling and professional installation to ensure smooth movement and structural stability.
- Access Speed: While highly efficient, users must wait a few seconds for the motorized aisle to open before accessing specific files, unlike open static shelves.
Application Scenarios
- Government & Municipal Archives: Ideal for storing massive volumes of historical records, policy documents, and blueprints.
- Universities & Public Libraries: Perfect for back-of-house storage of periodicals, theses, and rare book collections.
- Financial Institutions: Secure storage for decades of bank transaction records, contracts, and sensitive financial data.
- Corporate Records Rooms: Centralized management of HR files, legal paperwork, and internal compliance documents.
- Medical & Healthcare Facilities: Storing patient records, medical history, and laboratory archives securely.
Application Cases
- City Municipal Archive Project: Deployed 120 sections of heavy-duty compactor shelving to store over 500,000 historical documents. The high-density design saved 40% of floor space, allowing the facility to avoid costly off-site storage rentals.
- National University Library Expansion: Utilized for back-of-house periodical storage. The silent motor operation ensures zero noise disruption to adjacent reading rooms, while ergonomic handles provide easy access for library staff.
- Provincial Bank Vault Upgrade: Installed in secure vault rooms for storing decades of transaction records. The robust SPCC steel construction and electromagnetic locking systems provided the physical security required for sensitive financial data.
- Multinational Corporate HQ: Adopted for centralized records management. Customizable shelf heights accommodated everything from standard A4 binders to oversized legal ledgers, streamlining internal compliance and audit processes.
Technical Specifications
| Parameter | Standard Specification |
|---|---|
| Overall Dimensions | 2500mm (H) x 900mm (D) x 560mm (W) per section (Customizable) |
| Material | SPCC Cold-rolled steel (GB710 standard), Electrostatically sprayed |
| Power Supply | 220V AC / 50Hz (Converts to 24V DC for safety) |
| Motor Power | 120W (Low voltage, high torque, brushless DC) |
| Load Capacity | ≥80kg per shelf (Evenly distributed) |
| Transmission System | Double-row chain drive with precision bearings |
| Control Method | Touchscreen + Remote Control + Manual Override (Five-star handle) |
| Safety Features | Infrared anti-collision, Soft-landing proximity switch, Anti-tilt device, Electromagnetic locks |
| Network Interface | TCP/IP (Ethernet), CAN bus communication |
